Max. plasma cutting thickness: 15mm (configured with plasma power supply according to cutting thickness)
Working precision of plasma cutting: ±0.2mm/m
Voltage & frequency: e.g. 110V±10％, 220V±10％, 50-60Hz, 0.21HP(160W)
Weight: 800kg
49 pre-set patterns
Detachable, low shipping cost
Request a quote
GC-1530 CNC plasma cutting table is a detachable CNC cutting machine combining the features of high speed and high efficiency, suited to cut medium and thin metal sheets & plates that are being mass-produced. The cross beam is characterized by lightweight, small inertia, high precision and ease of installation.
Configured with plasma cutting torch, this CNC cutting table is an efficient energy-saving solution for industrial cutting applications. The detachable design is an important feature which can greatly save shipping cost and container space when shipping via sea.
Comparison
Ordinary cutting table occupies 15m3 space, with higher freight costs;
Detachable CNC cutting table needs only 7m3 space, with lower freight costs;
Cutting mode:
this CNC cutting table is configured with plasma cutting torch, suitable for fast cutting of medium and thin metal sheets & plates. The cutting speed ranges from 50 to 4000mm/min.
380V±10％VAC, 50/60HZ three phase 220V±10％V AC, 50/60HZ single phase
Plasma cutting
Plasma cutting thickness
0-15mm Depending on plasma power
Torch height control
Arc voltage torch height control
Gas types for plasma cutting
N2, O2, compressed air
Plasma cutter
63A-200A
Cutting torch
8m plasma cutting torch
CNC control system
F2100T
Motor
Stepper motor, servo motor
Working precision
±0.2mm/m
Guide rail size (L×W×T)
2500×2730×1500mm
Software
Starcam, Fastcam
Cutting mode changeover
Simple changeover between plasma and oxy-fuel cutting. Plasma cutting can be performed by adding plasma power supply, arc voltage torch height control and plasma cutting torch.
Materials
stainless steel
low carbon steel
carbon steel
alloy steel
spring steel
iron
galvanized iron
galvanized steel
aluminum
copper
brass
bronze
gold
silver
titanium
Industries
billboards
identification plates
metal channel letters
LED letters
kitchenware
metal parts & components
metal containers
metal enclosures
metal shelves
metal crafts & artworks
faceplates
hardware
auto parts
glasses frames
electronic components
Fangling Cutting Control System (F2100T Built-in Arc Voltage Height Control) The control system adopts 7 inch touch screen, with 49 pre-set patterns which can be easily selected by entering the corresponding number.
Functions
Pattern display
19-language menu
Pattern storage, 49 pre-set patterns
Metal plate adjustment
Automatic kerf compensation
Automatically memorize the last cutting point when power off
Cutting from current position
Offline cutting
Online upgrade
Double-axis Linear Guide Rail Adopting high precision linear guide rail, the guiderail in transverse motion is made of lightweight aluminum alloy which features high resistance to deformation, while the longitudinal guide rail offers high precision and stable operation.
Servo Motor, THC and DC Motor These components can work coordinately, providing better performance than that of those parts from different brands.
Limit Switch When cutting torch moves, the limit switch can protect the torch from damaging that is caused by direct impact to the machine.
Software FastCAM Pro is a professional software for plasma and flame cutting machines, it can read or convert various CAD file formats such as DXF, DWG and IGES.
