Gas types for flame cutting: Oxygen + Propane or Oxygen + Acetylene
Max. flame cutting thickness: 200mm(8 inch)
Max. plasma cutting thickness: 40mm (configured with plasma power supply according to cutting thickness)
Working precision of plasma cutting: ±0.2mm/m
Voltage & frequency: e.g. 110V±10％, 60Hz, 0.21HP(160W)
Weight: 1200kg
49 pre-set patterns
Request a quote
Gantry CNC plasma flame cutting machine combines the high speed and high efficiency of CNC cutting machine, with higher working precision than conventional handheld cutting machines. It adopts gantry structure with span options of 3m, 4m, 5m, 6m and 8m. The double sides drive provides stable operation and high work efficiency, allowing the cutting machine suited to cut carbon steel, manganese steel, stainless steel and other metal plates from small to large format. Furthermore, this CNC cutting machine can be offered with multiple cutting torches to meet user's individual production demands. Straight-line cutting and curved-line cutting are configurable as dual cutting mode in one machine to satisfy profile cutting needs.
What's more, capacitor sensor or plasma torch height control is optional. The machine construction is welded from high-strength steel and treated through tempering process for stress relief, then formed by using large machining center to guarantee the precision and finally subjected to the strict inspection and test process to meet rigid standards of excellence.
380V±10％VAC, 50/60HZ three phase 220V±10％V AC, 50/60HZ single phase
Flame cutting (oxy-fuel cutting)
Flame cutting thickness
1-200mm (Oxygen + Propane or Oxygen + Acetylene)
Torch height control
Electric flame height adjustment (±200mm)
Gas types for flame cutting
Oxygen + Propane or Oxygen + Acetylene
Cutting torch
One-piece cutting torch
Plasma cutting
Plasma cutting thickness
0-40mm
Torch height control
Arc voltage torch height control
Gas types for plasma cutting
N2, O2, compressed air
Plasma cutter
63A-400A
Cutting torch
8m plasma cutting torch
CNC control system
F2300B
Motor
Servo motor
Working precision
±0.2mm/m
Guide rail size (L×W×T)
3500×273×60mm
Software
FASTCAM
Cutting mode changeover
Simple changeover between plasma and oxy-fuel cutting. Plasma cutting can be performed by adding plasma power supply, arc voltage torch height control and plasma cutting torch.
Plasma cutting comes with plasma cutting torch to cut metal plate up to 40mm thickness, providing a fast cutting process;
Flame cutting capable of cutting thick metal plates, featuring wide applications with lower cost;
